JET 525 CNCProducts,Donatoni Macchine

JET 525 CNC

Click to view larger image.

Product:	JET 525 CNC
Price:	Bargain
Delivery Period:	Shipped within days from the date of payment of the buyers.
Last Updated:	30 Jul,2013
Valid Until：	Long-term effective

Detail

JET 525 CNC

It can be used in the building industry:

Window and door surrounds

Interior and exterior coverings

Stairs

Flooring

In interior furnishings in general:

Kitchen worktops

Bathroom tops

Tables

Shower trays (excavated with optional tools)

Thin to very thick frames

Low reliefs

	standard	tools
Maximum number of interpolated axes	N°	5	5
X axis carriage travel	mm.	3600	3600
Y axis bridge travel	mm.	2450	2400
Z axis head lift/lower travel	mm.	370	350
C axis disk head rotation	gradi-degrees	0°/370°	-5°/365°
A axis interpolated head inclination	gradi-degrees	0°/90°	0°/90°
Working table dimensions	mm.	2000X3500	2000X3500
Minimum disk diameter	mm.	400	350
Maximum disk diameter	mm.	625	525
Maximum cutting depth	mm.	200	140
Max spindle power	Kw-HP	17,6/24-S6	13-S6
Tool rotation with inverter	giri/min.-RPM	0 / 2400	0 /4300

Quotation

Donatoni Macchine
