Natural Tamala Limestone
Detail
Finish: Diamond Cut
Single Bullnoses
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS500 | 300 x 150 x 30 | 450 | 2 |
MS501 | 300 x 150 x 60 | 216 | 4 |
MS502 | 300 x 150 x 76 | 180 | 5 |
MS505 | 500 x 210 x 30 | 250 | 4 |
MS506 | 500 x 210 x 60 | 120 | 9 |
MS507 | 500 x 210 x 76 | 100 | 12 |
MS510 | 500 x 245 x 30 | 200 | 5 |
MS511 | 500 x 245 x 60 | 96 | 10 |
MS512 | 500 x 245 x 76 | 80 | 14 |
MS515 | 500 x 300 x 30 | 152 | 7 |
MS516 | 500 x 300 x 60 | 72 | 13 |
MS517 | 500 x 300 x 76 | 60 | 17 |
MS520 | 500 x 159 x 100 | 108 | 13 |
MS521 | 500 x 245 x 100 | 72 | 19 |
MS522 | 500 x 330 x 100 | 54 | 25 |
Specials
A – Mitre • B – Radius • C – Triple Mitre • D – Triple Radius
Double Bullnoses
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS525 | 300 x 150 x 30 | 450 | 2 |
MS526 | 300 x 150 x 60 | 216 | 4 |
MS527 | 300 x 150 x 76 | 180 | 5 |
MS530 | 500 x 210 x 30 | 250 | 4 |
MS531 | 500 x 210 x 60 | 120 | 9 |
MS532 | 500 x 210 x 76 | 100 | 12 |
MS535 | 500 x 245 x 30 | 200 | 5 |
MS536 | 500 x 245 x 60 | 96 | 10 |
MS537 | 500 x 245 x 76 | 80 | 14 |
MS540 | 500 x 300 x 30 | 152 | 7 |
MS541 | 500 x 300 x 60 | 72 | 13 |
MS542 | 500 x 300 x 76 | 60 | 17 |
MS545 | 500 x 159 x 100 | 108 | 13 |
MS546 | 500 x 245 x 100 | 72 | 19 |
MS547 | 500 x 330 x 100 | 54 | 25 |
Single Gothic
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS610 | 500 x 159 x 100 | 108 | 13 |
MS611 | 500 x 245 x 100 | 72 | 19 |
MS612 | 500 x 330 x 100 | 54 | 25 |
Double Gothic
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS620 | 500 x 159 x 100 | 108 | 13 |
MS621 | 500 x 245 x 100 | 72 | 19 |
MS622 | 500 x 330 x 100 | 54 | 25 |
Finish: Diamond Cut all Surfaces
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS650 | 250 x 245 x 119 | 64 | 11 |
MS651 | 250 x 330 x 119 | 48 | 15 |
MS652 | 330 x 245 x 160 | 54 | 19 |
MS653 | 330 x 330 x 160 | 54 | 26 |
MS654 | 400 x 245 x 195 | 48 | 28 |
MS655 | 400 x 330 x 195 | 30 | 38 |
Finish: Diamond Cut Faces / Quarry Cut Edges
MS660 | 350 x 350 x 165 | 54 | 30 |
Finish: Quarry Cut all Surfaces
MS661 | 500 x 350 x 240 | 24 | 65 |
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS690 | Gothic 310 x 310 x 100 to suit 250 square pier |
81 | 14 |
MS691 | Gothic 360 x 360 x 100 to suit 300 square pier-(2 halves) |
45 | 20 |
MS692 | Gothic 410 x 410 x 100 to suit 350 square pier-(2 halves) |
36 | 25 |
MS693 | Gothic 460 x 460 x 100 to suit 400 square pier-(2 halves) |
36 | 31 |
MS694 | Gothic 560 x 560 x 100 to suit 500 square pier-(2 halves) |
18 | 47 |
MS700 | Bullnose 310 x 310 x 100 to suit 250 square pier |
108 | 9 |
MS701 | Bullnose 410 x 410 x 100 to suit 350 square pier-(2 halves) |
48 | 15 |
MS702 | Bullnose 460 x 460 x 100 to suit 400 square pier-(2 halves) |
48 | 19 |
MS703 | Bullnose 560 x 560 x 60 to suit 500 square pier-(2 halves) |
24 | 28 |
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS550 | 500 x 150 x 76 1 course (splayed) |
210 | 8 |
MS551 | 500 x 150 x 76 1 course (half bullnose) |
210 | 8 |
MS552 | 500 x 150 x 76 1 course (bullnose) |
210 | 8 |
MS553 | 500 x 159 x 150 2 course (chamfer) |
72 | 18 |
MS554 | 500 x 159 x 150 2 course (splayed) |
72 | 18 |
MS555 | 500 x 159 x 150 2 course (double splayed) |
72 | 18 |
MS556 | 500 x 159 x 150 2 course (double chamfered) |
72 | 18 |
MS557 | 500 x 159 x 100 2 course (narrow splayed) |
108 | 12 |
Code | Style | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS800 | Tanami | 1 | 700 |
MS801 | Pilbarra | 1 | 650 |
MS802 | Kimberley | 1 | 750 |
MS803 | Murchison | 1 | 600 |
Garden Edging
Code | Size (mm) | No. Per Pallet | Kg Per Unit |
---|---|---|---|
MS730 | 500 x 245 x 100 (half bullnose) |
72 | 19 |
MS731 | 250 x 245 x 100 (chamfer) |
72 | 19 |
Geological Name: Tamala Eolianite
Stone Type: Coastal Limestone
Colour: Cream
Texture: Fine to medium grained
Geological Age: Pleistocene Age
Bulk Density: 1.5t/m³
Compressive Strength: 3.5 Mpa Avg
Calcium Carbonate Content: 70%-95%
Flexural Strength: 2.5MPa dry 2.2MPa wet
As with all natural materials variability in colour, texture and composition can be expected. Repeat testing is recommended to confirm suitability of technical specifications.
Natural Tamala Limestone:
