stone processing equipments
ZDMJ-16C Polishing machine for slab
|
Click to view larger image. |
|
Detail
| Polishing machine for slab | ZDMJ-6C | ZDMJ-14C | ZDMJ-16C | |
| No.of heads | nº | 6 | 14 | 16 |
| Useful working width | mm | 600-2000 | 600-2000 | 600-2000 |
| Useful working thickness | mm | 15-50 | 15-50 | 15-50 |
| Belt advancement speed | mm/min | 0-2500 | 0-2500 | 0-2500 |
| Spindle motor power | kw | 11 | 11 | 11 |
| Total power | kw | 73 | 162.6 | 184.6 |
| Water consumption | m3/h | 10 | 22 | 25 |
| Overall dimensions(LxWxH) | mm | 6540x3470x2560 | 10810x3970x2560 | 11900x3970x2560 |
